Out put De lay from –64 to +63.5 UI in 0.5 UI steps,
Ref er ence Out put ±(5% + 0.5 UI).
Re sid ual Jit ter £600 ps (700 Hz–100 kHz BW).
Miscellaneous Digital I/O
Trans mit Frame Sync Square wave at the pro grammed in ter nal sam ple
rate (SR).
Re ceive Frame Sync Square wave at the frame rate of the re ceived
AES/EBU sig nal.
Mas ter Clock Out Square wave at 256 x System Sample Rate
(SSR).
Selectable be tween jit tered and un-jittered
sig nals.
Aux il iary In put LSTTL com pat i ble trig ger in put for DSP pro gram
data ac qui si tion.
Aux il iary Out put HCMOS sig nal, func tion un der DSP pro gram
con trol.
Trig ger Out put HCMOS sig nal, co in ci dent with pe riod of
gen er ated sig nal wave form.
Par al lel In put and Out put For use with op tional PSIA-2722 accessory.
Chapter 6: Specifications Rear Panel Auxiliary Signals
88 Getting Started with Your 2700 Series Instrument
