Frequency Resolution
High-accuracy mode 0.005%.
Fast mode 0.025 Hz, 10 Hz–204.75 Hz,
0.25 Hz, 205 Hz–2.0475 kHz,
2.5 Hz, 2.05 kHz–20.475 kHz,
25 Hz, 20.5 kHz–204 kHz.
Amplitude Range
2
Balanced <10 µV–26.66 Vrms [+30.7 dBu].
Unbalanced <10 µV–13.33 Vrms [+24.7 dBu].
Amplitude Accuracy ±0.7% [±0.06 dB] at 1 kHz.
Amplitude Resolution 0.003 dB or 0.05 µVrms, whichever is larger.
Flatness (1 kHz ref)
10 Hz–20 Hz ±0.010 dB.
20 Hz–20 kHz ±0.008 dB (typically <0.003 dB).
20 kHz–50 kHz ±0.03 dB.
50 kHz–120 kHz ±0.10 dB.
120 kHz–200 kHz +0.2 / –0.3 dB.
Residual THD+N
3,4
At 1 kHz £(0.00025% + 1.0 µV) [–112 dB], 22 kHz BW
(valid only for analyzer inputs £8.5 Vrms).
20 Hz–20 kHz £(0.0003% + 1.0 µV) [–110.5 dB], 22 kHz BW,
£(0.0005% + 2.0 µV) [–106 dB], 80 kHz BW,
£(0.0010% + 5.0 µV) [–100 dB], 500 kHz BW.
10 Hz–100 kHz £(0.0040% + 5.0 µV) [–88 dB], 500 kHz BW.
Intermodulation Distortion Test Signals
with option “IMD”
SMPTE (or DIN)
LF Tone 40, 50, 60, 70, 100, 125, 250, or 500 Hz,
all ±1.5%.
HF Tone Range 2 kHz–200 kHz.
Mix Ratio 4:1 or 1:1 (LF:HF).
Amplitude Range
5
Balanced 30 µVpp–75.4 Vpp.
Unbalanced 30 µVpp–37.7 Vpp.
Amplitude Accuracy ±2.0% [±0.17 dB].
Residual IMD
6
0.0015% [–96.5 dB],
60 Hz + 7 kHz or 250 Hz + 8 kHz.
Chapter 6: Specifications Analog Signal Outputs
52 Getting Started with Your 2700 Series Instrument
2
20 Hz–50 kHz only. Decrease maximum output by a factor of 2 (–6.02 dB) for the full 10 Hz–204 kHz range.
3
System specification measured with the 2700 series analog analyzer set to the indicated measurement
bandwidth (BW). Generator amplitude setting must be £12 Vrms balanced or £6 Vrms unbalanced for
specified performance below 30 Hz. At higher amplitude settings generator THD derates to 0.0020% from
20 Hz–30 Hz.
4
Individual harmonics are typically <–130 dBc at 1 kHz, and <–120 dBc from 25 Hz to 20 kHz measured with a
passive notch filter and FFT analyzer.
5
Calibration with other amplitude units is based upon an equivalent sinewave having the same Vpp amplitude.
6
System specification measured with the 2700 series analog analyzer at any amplitude ³200 mVrms.
