Flatness (1 kHz ref)
12
20 Hz–20 kHz ±0.008 dB (typically <0.003 dB).
15 Hz–50 kHz ±0.03 dB.
10 Hz–120 kHz ±0.10 dB.
120 kHz–200 kHz +0.2 / –0.3 dB (typically <–0.5 dB at 500 kHz).
Frequency Meter Related
Measurement Range 10 Hz–500 kHz.
Accuracy ±0.0006% [±6 PPM].
Resolution 6 digits + 0.000244 Hz.
Minimum Input 5 mV.
Phase Measurement Related
Measurement Ranges ±180, –90 / +270, or 0 / +360 deg.
Accuracy
13
10 Hz–5 kHz ±0.5 deg.
5 kHz–20 kHz ±1 deg.
20 kHz–50 kHz ±2 deg.
Resolution 0.1 deg.
Minimum Input 5 mV, both inputs.
Wideband Amplitude/Noise Function
Measurement Range <1 µV–160 Vrms.
Accuracy (1 kHz) ±1.0% [±0.09 dB].
Flatness (1 kHz ref)
12
20 Hz–20 kHz ±0.02 dB.
15 Hz–50 kHz ±0.05 dB.
50 kHz–120 kHz ±0.15 dB.
120 kHz–200 kHz +0.2 dB / –0.3 dB (typically < –3 dB at 500 kHz).
Analog Analyzer Chapter 6: Specifications
Getting Started with Your 2700 Series Instrument 59
12
Derate flatness above 5 kHz by an additional ±0.02 dB in the 20 V, 40 V, 80 V, and 160 V input ranges.
13
Both analyzer input channels must have same coupling (ac or dc) selection. Accuracy is valid for any input
signal amplitude ratio up to ±30 dB.
