Precision De-emphasis Family
FIL-D50 50 µs ±1%. –see Figure 42
FIL-D50E 50 µs ±1% + 15.625 kHz notch.
FIL-D50F 50 µs ±1% + 19.0 kHz notch. –see Figure 43
FIL-D75 75 µs ±1%. –see Figure 44
FIL-D75B 75 µs ±1% + 15.734 kHz notch. –see Figure 45
FIL-D75F 75 µs ±1% + 19.0 kHz notch. –see Figure 46
Option Filters Chapter 6: Specifications
Getting Started with Your 2700 Series Instrument 65
Figure 42. FIL-D50.50 µs De-emphasis
Filter.
Figure 43. FIL-D50F. 50 µs with 19 kHz
(FM) notch De-emphasis Filter.
Figure 44. FIL-D75. 75 µs De-emphasis
Filter.
Figure 45. FIL-D75B. 75 µs with 15.734
kHz (NTSC) notch De-emphasis Filter.
Figure 46. FIL-D75F. 75 µs with 19 kHz
(FM) notch De-emphasis Filter.
