Receiver Testing
FIL-RCR 200 Hz–15 kHz + 19.0 kHz notch. –see Figure 52
FIL-IECR 20 Hz–15 kHz + 15.625 kHz notch –see Figure 53
Miscellaneous
FBP-500X High-Q 500 Hz bandpass for CD DAC linearity
measurements. –see Figure 54
FIL-USR Kit for building custom filters.
Chapter 6: Specifications Option Filters
68 Getting Started with Your 2700 Series Instrument
Figure 52. FIL-RCR. 200 Hz to 15 kHz with
19 kHz (FM) notch.
Figure 53. FIL-IECR. 20 Hz to 15 kHz with
15.625 kHz (PAL) notch.
Figure 54. FBP-500X. High-
Q 500 Hz Band Pass Filter
(for CD linearity testing).
