29
Parameter
Specification
MaxiCharger DC 120 MaxiCharger DC 240
Z
500 mm 19.69 in 500 mm 19.69 in
H1
150 mm 5.9 in 150 mm 5.9 in
H2
100 mm 3.94 in 100 mm 3.94 in
H3
350 mm 13.78 in 350 mm 13.78 in
NOTE
Make sure the angle and diameter of the conduit meet the requirements for wires
to be guided through.
Make sure the size of the marked area (C) meets the specifications shown in Table
5-6 Drilling Holes Specifications. The area (C) is marked in Figure 5-4 Drilling Holes.
IMPORTANT
The foundation needs to be 150 mm above the surface.
Let the concrete dry.
Pull the wires through the conduit. Apply the cable slack according to the
following specifications.
Table 5-5 Cable Slack Specifications
Parameter
Specification
mm in
Required Cable Slack for the
Ethernet Cable (Measured from the
Top of the Foundation)
750 29.53
Required Cable Slack for the AC
Input Cable (Measured from the Top
of the Foundation)
600 23.62
To Next Page
