AUX air conditioner service manual
100
Detailed part list of ASW-H09A4/ET outdoor unit
No Chinese Name Name Material Number
1 面板网罩 Steel grille 1
2 面板组件 Front panel 1
3 顶盖板 Top cover board 1
4 轴流风叶 Outdoor fan 1
5 室外电机 Outdoor fan motor 1
6 电机架 Motor bracket 1
7 冷凝器组件 Condenser assembly 1
8 冷凝器进气管 Condenser gas inlet tube 1
9 毛细管组件 Capillary assembly 1
10 后钢丝网罩 Backside steel grille 1
11 电器盖板 Handle 1
12 右侧板 Right-side plate 1
13 电容抱攀 Capacitor clamp 1
14 风机电容 Fan motor capacitor 1
15 压缩机电容 Compressor capacitor 1
16 端子板 Terminal board 1
17 电器架 Electrical holding plate 1
18 隔风立板 Partition plate 1
19 四通阀线圈 Electromagnetic loop 1
20 四通阀管路组件 Four-way valve and capillary
assembly
1
21 压缩机连接线 Compressor connection cord 1
22 压缩机接地线 Compressor grounding cord 1
23 电器罩 Compressor terminal cover 1
24 过载保护器 Over-load protector 1
25 压缩机 Compressor 1
26 截止阀组件 A Liquid valve 1
27 截止阀组件 B Gas valve 1
28 阀板 Valve plate 1
29 底盘组件 Chassis 1
