51
timing range is 1min.-24hour. The air-conditioner stops automatically once the setting timing reached.
②Timing turns on
The timing turns on function can be set only under the running status of the air-conditioner. The
timing range is 1min.-24hour. The air-conditioner turns on automatically once the setting timing
reached. The turning on and turning off action happen after setting timing set will cancel the previous
set setting timing and sleeping functions
⑾ Self-detecting function
Press the Emergency button and electrify the air-conditioner, the self-detecting process starts
after the buzzer delivers short tone twice:
Start the electric heating, run the indoor fan at a high fan speed, open the air door to be the
maximum Æthe digital display and three indicating light on in 1 secondÆ digital displays
“11”、“22”、“33”、“44” in turn and 1second for each of them ÆWorking light on 1 second
ÆTiming light on 1 second ÆSleeping light on 1 second ÆEach phase of the stepping motor
moves in 1 second Æthe indoor fan runs for 1 second at low fan speed and middle fan speed
separatelyÆthe compressor moves for 1 second ÆThe four-way valve moves for 1 second
ÆOutdoor fan moves for 1 second ÆNegative ion generator moves for 1 second Æbuzzer
deliver one short toneÆElectric heating runs 30 Seconds and stops, then the air conditioner
turn into the waiting status, the self-testing is ended.
⑿Fault indication
When there is faults happen to the air-conditioner, the timing lights on the display panel will indicate
the corresponding fault codes, which are specifically reflected as the following:
For LED display:
FAULT DISPLAY MODE DISPLAY
PRIORITY
APPEARANCE
TA
abnormity
Timer lamp flash 1
times/8 seconds
2 AC stopped
TE
abnormity
Timer lamp flash
2 times/8 seconds
3 AC stopped
TW
abnormity
Timer lamp flash
8 times/8 seconds
4 AC hasn’t stopped
For Digital display:
FAULT DISPLAY
MODE
DISPLAY
PRIORITY
APPEARANCE
TA abnormity display“E1” 2 AC stopped
TE abnormity display “E3” 3 AC stopped
TW abnormity display “E2” 4 AC hasn’t stopped
⒀The definition of the swing angle
(Picture 3)It shows the swing angles of the types 18000BTU and 24000BTU stepping motor，the air
