Detailed part list of ASW-H12A4/EC indoor unit
No Chinese Name Name Material Number
1 面板组件 Panel 1
2 杀菌过滤网 Anti-bacterial Filter 2
3 维 C 防螨过滤网 Vitamin-C & Anti-mites Filter 2
4 过滤网组件 Filter 2
5 螺钉盖 Screw cover 3
6 中框盖 Cover of Medium frame 1
7 中框组件 Medium frame 1
8 导风门 Horizontal air blade 1
9 导风叶片 Vertical air blade 2
10 导风架 Air blade holder 1
11 步进电机组件 Step motor 1
12 贯流风叶组件 Indoor fan 1
13 橡胶轴承座 Rubber bearing 1
14 蒸发器左支架 Left plastic crutch for evaporator 1
15 蒸发器总成 Evaporator 1
16 底座组件 Chassis 1
17 挂板组件 Mounting plate 1
18 管路压板 Tube clamp plate 1
19 塑封电机组件 Indoor fan motor 1
20 电机盖 Cover for indoor fan motor 1
21 电控盒 Electric controller box 1
22 变压器 Transformer 1
23 室内传感器 Plastic temperature sensor 1
24 主控板 Main PCB 1
25 内盘传感器 Copper temperature sensor 1
26 遥控器接收座 Signal receiver holder for Remote
controller
1
27 温控探头支架 Temperature sensor holder 1
28 接收板 Receiver board 1
29 端子板 Terminal board 1
30 负离子发生器 Negative ion generator 1
31 连接线 Connection cable 1
32 电源连接线 Interconnection cord 1
33 电源线 Power supply cord with plug 1
34 指示灯座 Indication lamp holder 1
35 显示板 Display board 1
36 遥控器 Remote controller 1
