AUX air conditioner service manual
116
Detailed part list of ASW-H18B4/ET outdoor unit
No Chinese Name Name Material Number
1 左侧支撑板 Left-side supporting plate 1
2 钢丝网罩 Steel grille 1
3 大扁头自攻螺钉 Screw 4
4 顶盖板 Top cover board 1
5 大面板 Front panel 1
6 冷凝器总成 Condenser assembly 1
7 右侧板 Right-side panel plate 1
8 小挖手 Handle 2
9 电容抱攀 Capacitor clamp 1
10 压缩机电容 Compressor capacitor 1
11 电机电容 Fan motor capacitor 1
12 压线板 Wiring clamping cover 1
13 电器架 Electrical holding plate 1
14 五位端子板 Terminal board 1
15 隔风立板 Partition plate 1
16 压缩机 Compressor 1
17 毛细管组件 Capillary assembly 1
18 四通阀管路组件 Four-way valve assembly 1
19 截止阀组件 Dg4 Liquid valve Dg4 1
20 截止阀组件 Dg10 Gas valve Dg10 1
21 底盘组件 Chassis 1
22 十字槽自攻螺钉 Screw 4
23 阀板 Valve plate 1
24 轴流风叶 Outdoor fan 1
25 电机架 Motor bracket 1
26 室外风叶电机 Outdoor fan motor 1
27 十字槽盘头螺钉 Screw 4
