AUX air conditioner service manual
142
Detailed part list of ASF-H24B4/FS indoor unit
No Chinese Name Name Material Number
1 顶盖板组件 Top cover plate 1
2 电热窗盖板组件 Cover assembly for
Electric-heater
1
3 右侧板组件 Right-side plate 1
4 底盘 Chassis 1
5 室内风叶电机组件 Indoor fan motor 1
6 控制器组件 Controller 1
7 电控盒组件 Electric controller box 1
8 离心风叶组件 Centrifugal fan blade 1
9 风机垫片 Cushion for fan motor 1
10 标准型弹簧垫圈 Spring gasket 1
11 I 型六角螺母 Hexangular nut 1
12 电控盒盖板组件 Cover for electric controller box 1
13 蜗牛壳 Hodmadod shell 1
14 蜗壳支撑板 Supporting plate for Hodmadod
shell
1
15 进风口导风圈 Air-inlet guiding ring 1
16 压线座组件 Wiring clamping holder 1
17 压线盖 Wiring clamping cover 1
18 双联压线座组件 Double-line clamping holder 1
19 双联压线盖 Double-line clamping cover 1
20 过滤网组件 Filter 1
21 进风格栅
总成
Grille assembly 1
22 中面板 Medium panel 1
23 显示面板组件 Indication panel 1
24 出风窗组件 Air outlet grille assembly 1
25 集水槽 Water collecting slot 1
26 保温盖板 Heat-preservation cover 1
27 灯座组件 Lamp holder assembly 1
28 蒸发器下托板组件 Below supporting assembly for
evaporator
1
29 蒸发器右安装板 Right fixing board for evaporator 1
30 蒸发器组件 Evaporator assembly 1
31 蒸发器上安装板 Upper fixing board for
evaporator
1
32 蒸发器左安装板 Left fixing board for evaporator 1
33 卡扣 Clip 4
34 右侧板组件 Right-side plate 1
35 背板组件 Back-side plate 1
