AUX air conditioner service manual
118
Detailed part list of ASW-H24B4/ET indoor unit
No Chinese Name Name Material Number
1 面板组件 Panel 1
2 大扁头自攻螺钉 Screw 9
3 电控盒盖 Cover of medium frame 1
4 螺钉盖 Screw cover 3
5 大扁头自攻螺钉 Self-drill screw 3
6 导风门 A Horizontal air blade A 1
7 导风门 B Horizontal air blade B 1
8 导风门连杆 Connection-pole of horizontal
air blade
1
9 步进电机组件 Step motor 1
10 十字槽自攻螺钉 Screw 1
11 大扁头自攻螺钉 Screw 12
12 压线板 Wiring clamping cover 1
13 导风架组件 Air blade holder 1
14 控制器总成 Electric controller assembly 1
15 抽头塑封电机组件 Indoor fan motor 1
16 管路压攀 Pipe clamp 1
17 挂板组件 Mounting plate 1
18 底座组件 Chassis 1
19 贯流风叶组件 Indoor fan 1
20 橡胶轴承座组件 Rubber bearing 1
21 蒸发器总成 Evaporator assembly 1
22 蒸发器支架 Left plastic crutch for evaporator 1
23 中框组件 Medium frame 1
24 过滤网 Filter 2
