Page #123 background imageLoading...
Page #123 background image
AUX air conditioner service manual
120
Detailed part list of ASW-H24B4/ET outdoor unit
No Chinese Name Name Material Number
1 左侧支撑板 Left-side supporting plate 1
2 钢丝网罩 Steel grille 1
3 大扁头自攻螺钉 Screw 4
4 顶盖板 Top cover board 1
5 大面板 Front panel 1
6 冷凝器总成 Condenser assembly 1
7 右侧板 Right-side panel plate 1
8 小挖手 Handle 2
9 电容抱攀 Capacitor clamp 1
10 压缩机电容 Compressor capacitor 1
11 单极交流接触器 AC Contactor 1
12 电机电容 Fan motor capacitor 1
13 压线板 Wiring clamping cover 1
14 电器架 Electrical holding plate 1
15 五位端子板 Terminal board 1
16 隔风立板 Partition plate 1
17 压缩机 Compressor 1
18 毛细管组件 Capillary assembly 1
19 四通阀管路组件 Four-way valve assembly 1
20 截止阀组件 Dg8 Liquid valve Dg8 1
21 截止阀组件 Dg13 Gas valve Dg13 1
22 底盘组件 Chassis 1
23 十字槽自攻螺钉 Screw 4
24 阀板 Valve plate 1
25 轴流风叶 Outdoor fan 1
26 电机架 Motor bracket 1
27 室外风叶电机 Outdoor fan motor 1
28 十字槽盘头螺钉 Screw 4
