AUX air conditioner service manual
147
Detailed part list of ASF-H41A5/C indoor unit
No Chinese Name Name Material Number
1 顶盖板组件 Top cover assembly 1
2 右侧板组件 Right-side plate assembly 1
3 底盘 Chassis 1
4 室内风叶电机组件 Fan motor assembly 1
5 电控盒组件 Electric controller box 1
6 控制器(主控板) Controller 1
7 离心风叶组件 Centrifugal fan blade 1
8 电控盒盖板组件 Cover for electric controller box 1
9 蜗牛壳组件 Hodmadod shell 1
10 进风口导风圈 Air-inlet guiding ring 1
11 过滤网组件 Filter 1
12 进风格栅组件 Air-inlet grille assembly 1
13 中面板组件 Medium front panel 1
14 触摸式控制板 Touchable control screen 1
15 出风窗组件 Air-outlet grille assembly 1
16 摇风电机 Swing step 1
17 保温盖板组件 Heat-preservation cover 1
18 灯座组件 Lamp holder assembly 1
19
蒸发器下托板组件
Below supporting assembly for
evaporator
1
20 电加热组件 Electric-heater assembly 1
21 电加热防护网罩 Defense net of Electric-heater 1
22 蒸发器左安装板 Left fixing board for evaporator 1
23 蒸发器组件 Evaporator assembly 1
24 蒸发器上安装板 Upper fixing board for evaporator 1
25 蒸发器右安装板 Right fixing board for evaporator 1
26 左侧板组件 Left-side plate 1
27 背板组件 Backside plate 1
28 蒸发器进液管组件 Liquid inlet tube of evaporator 1
29
出气支管 A Outlet-tube branch A
1
30 出气支管 B Outlet-tube branch B 1
31 出气集管 Outlet-tubes assemble 1
32 分路体 Distributor 1
33 蒸发器出气管组件 Gas outlet tube of evaporator 1
34 蒸发器进液管组件 Liquid inlet tube of evaporator 1
35 保温套管 1 Heat-preservation casing tube 1 1
36 保温套管 2 Heat-preservation casing tube 2 1
37 橡胶挡水管 Rubber drain-water collector 1
38 单接头(Dg16) Single joint(Dg16) 1
39 塑料盖帽(Dg8) Plastic cap(Dg8) 1
40 单接头(Dg8) Single joint(Dg8) 1
41 塑料盖帽(Dg16) Plastic cap(Dg16) 1
42 集水槽组件 Water collecting slot 1
43 出水管组件 Drain pipe 1
