AUX air conditioner service manual
140
Detailed part list of ASW-H24B4/HS outdoor unit
No Chinese Name Name Material Number
1 左侧支撑板 Left-side supporting plate 1
2 钢丝网罩 Steel grille 1
3 大扁头自攻螺钉 Screw 40
4 顶盖板 Top cover plate 1
5 大面板 Front panel 1
6 冷凝器总成 Condenser assembly 1
7 右侧板 Right-side plate 1
8 小挖手 Handle 2
9 电容抱攀 Capacitor clamp 1
10 压缩机电容 Compressor capacitor 1
11 单级交流接触器 AC Connector 1
12 风机电容 Fan motor capacitor 1
13 压线盖 Wiring clamping cover 1
14 电器架 Electrical holding plate 1
15 五位端子板 Terminal board 1
16 隔风立板组件 Partition plate 1
17 压缩机组件 Compressor 1
18 毛细管管路组件 Capillary assembly 1
19 四通阀管路组件 Four-way valve and capillary
assembly
1
20 截止阀组件 Dg8 Liquid valve 1
21 截止阀组件 Dg13 Gas valve 1
22 底盘组件 Chassis 1
23 十字槽凹穴六角头自攻螺
钉和平垫圈组合件
Screw and cushion assembly 4
24 阀板 Valve plate 1
25 轴流风叶 Outdoor fan 1
26 电机架 Motor bracket 1
27 室外风叶电机组件 Outdoor fan motor 1
28 十字槽盘头自攻螺钉 Screw 4
