AUX air conditioner service manual
122
Detailed part list of ASW-H09A4/HSF indoor unit
No Chinese Name Name Material Number
1 面板组件 Panel 1
2 过滤网组件 Filter 2
3 电器盖板 Cover of medium frame 1
4 中框盖 Medium frame 1
5 导风门 Horizontal air blade 1
6 导风叶片 Vertical air blade 12
7 导风架 Air blade holder 1
8 步进电机组件 Step motor 1
9 贯流风叶组件 Indoor fan 1
10 橡胶轴承座 Rubber bearing 1
11 蒸发器左支架 Left plastic crutch for evaporator 1
12 蒸发器总成 Evaporator assembly 1
13 底座组件 Chassis 1
14 挂板组件 Mounting plate 1
15 管路压板 Tube clamp plate 1
16 塑封电机组件 Indoor fan motor 1
17 电控盒 Electric controller box 1
18 变压器 Transformer 1
19 室内传感器 Plastic temperature sensor 1
20 主控板 Main PCB 1
21 内盘传感器 Copper temperature sensor 1
22 遥控器接收座 Signal receiver holder for
Remote controller
1
23 温控探头支架 Temperature sensor holder 1
24 接收板 Receiver board 1
25 端子板 Terminal board 1
26 负离子发生器 Negative ion generator Optional 1
27 连接线 Connection cable 1
28 电源连接线 Interconnection cord 1
29 电源线 Power supply cord with plug 1
30 显示灯板 Display board 1
31 遥控器 Remote controller “I feel” function
optional
1
