exit to leave the second-level incoming-routing context and return to the (super-
sls)# context, and then enter clear internal-routing tgnum mode.
2. Enter set match-pattern pattern to define the beginning digit pattern of an
incoming alphanumeric dial string to be matched against.
3. Enter set length length to define the length of the dialed string.
4. If the mode is set to enbloc (in Step 1), you must:
• Enter set delete-digits digits to define the number of digits to be
deleted from a dialed string.
• Enter set insert-digits digits to define the number of digits to be
inserted at the beginning of a dialed string.
5. Optional. If the mode is set to overlap (in Step 1), you may configure only one of
the following options:
• Enter set delete-digits digits to define the number of digits to be
deleted from a dialed string.
• Enter set insert-digits digits to define the number of digits to be
inserted at the beginning of a dialed string.
Note that this action takes place after the deletion task has been completed for the
enbloc-receiving mode.
6. Enter exit to leave the incoming-routing context in SLS.
7. Enter show to check the incoming-routing administration.
The report lists the incoming-routing parameters for all dial patterns that have been
administered. For example:
Match_pattern Length Del Insert-digits Mode tgnum
------------- ------ --- ------------- ------ -----
234 7 3 5381000 enbloc 98
235 7 3 5381001 enbloc 99
Summary of SLS configuration commands
For more information about these commands, see the Avaya Branch Gateway G430 CLI
Reference.
Root Level
Commands
First Level Context
Commands
Second Level
Context
Commands
Description
set sls Enable or disable SLS
Standard Local Survivability (SLS)
Administering Avaya G430 Branch Gateway October 2013 187
