restore usb command to restore these files as well as the administration and configuration
files.
Note:
The CLI backup config usb and restore usb commands (for efficient backup/restore
using a USB mass storage device) only run on Branch Gateways R4.0 and higher.
You can also use the USB mass storage device to copy individual Branch Gateway files to or
from the Branch Gateway. Refer to
Upgrading software and firmware using a USB mass
storage device on page 86 and Software and firmware uploads from the Branch Gateway.
Tip:
Use a USB mass storage device with LED indication.
Related topics:
Backing up administration and configuration files using a USB mass-storage device on
page 91
Sample backup directory after backup on page 92
Restoring backed up configuration and administration files to a Branch Gateway using a USB
mass-storage device on page 93
Replicating a Branch Gateway using a USB mass-storage device on page 93
Sample backup directory after replication on page 96
Replacing/adding/upgrading media modules using a USB mass-storage device on page
97
USB backup, restore, and replication commands on page 97
Backing up administration and configuration files using a USB mass-storage
device
About this task
The following procedure backs up all the Branch Gateway configuration and administration
files, but does not back up any firmware files.
Back up the Branch Gateway regularly to a USB mass-storage device. This backup can be
very helpful in restoring the Branch Gateway’s configuration if it becomes faulty, or in restoring
the entire Branch Gateway.
Use at least a 128 MB USB mass-storage device since it can hold two full backup directories
with all images and configuration files. You can create multiple backup directories as long as
there is space in the USB mass-storage device.
Procedure
1. Connect a USB mass-storage device to the Branch Gateway USB port.
2. Type s to commit the current configuration to NVRAM.
Basic device configuration
Administering Avaya G430 Branch Gateway October 2013 91
