IFD500 Series Pilot Guide
Map Subsystem 4-3
Heading Up or Track Up (360°)
Heading Up or Track Up (240° arc view)
North Up (360°)
Heading vs. Track selection is made from the “Map Orientation”
selection on the Setup Page.
North-Up, 360 View Example
NOTE
Chart Data Reliance
Always refer to current aeronautical charts for
appropriate terrain and obstacle information. Do not
rely on the IFD as your sole source of obstacle and
terrain avoidance information.
