IFD500 Series Pilot Guide
4-4 Map Subsystem
North Up can be either Magnetic North or True North depending on
the “Bearing Reference” selection on the Setup Page.
Track-Up, Arc View Example
TIPS AND TECHNIQUES
Map Content Control
Map features displayed are highly dependent on a
combination of the map view, map range, map declutter
settings, and user setup choices. For example, if the
flight plan concludes at an airfield, the airfield identifier
may be automatically decluttered in favor of the
waypoint identifier that represents the airfield from the
flight plan. In this example, both identifiers can be
made visible by ranging in the map to under 4nm.
