Avision AD280 - Page 75

6-52
Reassembling:
While installing the long spring back to the bottom base, insert the long spring into the narrow slot
with its 2 ends into the 2 slots for the top cover, as shown below:
Be sure the protruding part (the blue thing enlarged) of the long spring is kept into place.
Insert 2 ends into
for the top cover.
