Avision AD280 - Cable Connection; Power Supply

3-3
3.2.2 Cable Connection
3.2.3 Power supply
In this system, there is only one type of power supply. Please see Table 3.1 for
details.
Table 3.1 Power Adapter
Type
Characteristic
Wall-mount
Input voltage range 100-240V
Input current (at the
rated input/output)
2A type or less
Input frequency 50-60Hz
Max. in-rush
current(@full load,
cold start)
45A
Output voltage +24Vdc
Min. load current 0.0A
Max. load current 2A
Total power (at full
load)
48W
