Avision AD280 - Removing the LED Light Bar from the Bottom Base

6-70
6.1.34 Removing the LED Light Bar from the Bottom Base
1. Remove the Feeding Rollers as described in the preceding section 6.1.33.
2. Remove 2 fixing screws on the LED light bar, as indicated below:
(Torque：8±0.5Kgf.cm / Screw Type: +B-H, TAP-2, 3x10 / PN: 077-1010-0)
3. Disconnect the cable from the LED light bar to remove the LED light bar.
LED Light Bar
(Bottom Base)
