ALPS N-type 90° ultra smooth 100 mm sliders are provided on series.
The scale shows the attenuation. Normal operating position is at the top „0‟ mark,
providing overall 0 dB of gain.
On request, to notify at order, ALPS K/VCA series sliders can be also fitted, the
last ones controlling the internal high quality VCA circuitry. There is no audio going
through the VCA faders. VCA faders do not therefore suffer from such severe
noise and signal loss problems that conventional faders may have when wear and
tear causes the resistive surface to deteriorate. The benefit is longer fader life, as
the crackles and dropouts typical of the traditional audio faders are smoothed out.
