The telco module interfaces an external telephone hybrid with the console. A
separate hybrid foe each Telco module will be required.
It features two gain controls, PFL, Master and Sub output select, hybrid
remote controls. It has only one mono input (Receive), the other Jack
connector being used for the mix minus output (Send) to the telephone
hybrid. The mix minus signal is the programme output signal with the phone
signal (caller’s voice) removed.
The engineer (or the presenter) can talk off-air with a caller (whilst the Main
programme is being output) via its own microphone (connected to Mono module
and routed as TB to Studio) or the TB microphone built-in into the Monitor
module..
The ‘Hook’ button becomes the Line Hook Remote Divert control for suitable
hybrids via the remote connector.
A ‘RING‟ LED (next to the Hook button) is provided for signalling of incoming
calls.
ALPS N-type 90° ultra smooth 100 mm sliders are provided on series. On
request, to notify at order, ALPS K/VCA series sliders can be also fitted, the last
ones controlling an internal high quality VCA circuitry.
