FACTORY PRESET CONSOLE CONFIGURATION
ENG
Axel Technology srl www.axeltechnology.com FACTORY PRESET
CONSOLE CONFIGURATION
11.1 MODULE REMOVING AND INSTALLATION
Input modules can be removed and installed ONLY with the console powered off.
TO REMOVE A MODULE FROM THE MAINFRAME:
Unscrew the screw at the top of the module
Unscrew the screw at the bottom of the module
Unplug the module from the (internal) rear input board
Unplug the module from the multipolar main flat cable (signal bus)
To remove a rear Input board from the mainframe
Follow all the steps at the Point 1
Unscrew the screw at the top of the rear plate
Unscrew the screw at the bottom of the rear plate
11.2 ALIGNEMENT OF INPUTS
When plugging in a new source start with the channel muted or fader turned down and the PFL activated. This prevents any
unexpected signal in the loudspeakers. The signal is displayed on the MONITOR meters.
Adjust the channel GAIN control for an average channel meter reading of „0‟ with loud moments lighting „+3‟.
Adjust the Gain trimmers on Mono rear modules if the signal is still too high with the main Gain turned down. It may be
necessary to re-adjust the gain if changes are made to the equaliser or inserted signal processing.
