FIRST INSTALLATION RECOMMENDATIONS
ENG
Axel Technology srl www.axeltechnology.com FIRST INSTALLATION
RECOMMENDATIONS
Use balanced connections where possible as these provide further immunity by cancelling out
interference that may be picked up on long cable runs. To connect an unbalanced source to a console input (balanced),
link the cold input (XLR pin 3 or jack ring) to 0V earth (XLR pin 1 or jack ground) at the console. To connect the console
output (balanced) to an unbalanced destination, link the cold output to 0V earth at the console.
Use good quality cables and connectors and check for correct wiring and reliable solder joints. Allow
sufficient cable loop to prevent damage through stretching.
If you are not sure ... Contact your Axel Technology agent for advice.
9.7 POSITION
The console should be located in a convenient space commensurate with the use to which the console is being put.
Ideally a cool area is preferred not in close proximity to power distribution equipment or other potential sources of
interference. Provision should be made for some flat surface surrounding the console to prevent people using it as a
table top.
