Axel Oxygen 4 User Manual

OXYGEN 4 TECHNICAL SPECIFICATIONS ENG
Axel Technology srl www.axeltechnology.com OXYGEN 4 TECHNICAL
SPECIFICATIONS
74
21 OXYGEN 4 TECHNICAL SPECIFICATIONS
STEREO MODULE
INPUT A
Stereo
El. Bal.
jack 1/4”
INPUT A nominal level
0 dBm (LINE)
-15 to +15 dB gain control
INPUT A impedance
10 kOhm
INPUT B
Stereo
jack 1/4”
INPUT B levels (jumper
select)
0 dBm (LINE)
El. Bal
-15 to +15 dB gain control
Phono (RIAA)
Unbal
-15 to +15 dB gain control
INPUT B line impedance
10 kOhm
MONO MODULE
INPUT A
Mono
El. Bal.
XLR
INPUT A adj level range
- 70 dB to - 23 dB (MICRO level)
-15 to +15 dB gain control
INPUT A insert level
0 dBm
Unbal.
jack 1/4”
INPUT A impedance
> 1,5 kOhm
INPUT B
Mono
El. Bal.
Jack 1/4”
INPUT A nominal level
0 dBm (LINE)
-15 to +15 dB gain control
INPUT B impedance
10 kOhm
TELEPHONE MODULE
SEND / RECEIVE separ.
20 dB**
** it can vary depending on telephone line characteristics
In / out level on tel. line
-6 dBm on 600 Ohm line imped.
Compensation mode
Electronic / automatic
TELCO MODULE
SEND Output
Mono
El. Bal.
Jack 1/4”
SEND level
0 dBm
-15 to +15 dB gain control
RECEIVE Input
Mono
El. Bal.
Jack 1/4”
-
RECEIVE level
0 dBm
-15 to +15 dB gain control
MASTER / SUB MODULE
SUB Output
Stereo
El. Bal.
Jack 1/4”
Nominal SUB Output Level
0 dBu (LINE)
Max SUB Output level
+ 20,5 dBm (25 Vpp)
SUB Output Impedance
50 Ohm
Noise (DIN Audio)
less than - 89 dBm
Crosstalk L/R
< - 60 dB @ 1 kHz
THD+N
< - 73 dB @ 1 kHz
Frequency response
20 Hz to 20 kHz (- 0.2 dB)
MASTER Output
Stereo
El. Bal.
Jack 1/4”
Nominal MST Output Level
0 dBu (LINE)
Max MST output level
+ 20,5 dBm (25 Vpp)
MST output Impedance
50 Ohm
Noise (DIN Audio)
less than - 87 dBm
Crosstalk L/R
< - 60 dB @ 1 kHz
THD+N
< - 74 dB @ 1 kHz
Frequency response
20 Hz to 20 kHz (- 0.5 dB)
REC1 – REC2 OUTPUT
Stereo
El. Bal.
Jack 1/4”
-inf to + 15 dBm
MONITOR MODULE
TUNER IN
Stereo Line
El. Bal.
Jack 1/4”
-15 to +15 dB gain
STUDIO Output
Spk - Stereo Line
Unbal.
Jack 1/4”
-inf to +6 dBm
Phones - Stereo Line
Unbal.
Jack 1/4”
0 to 24 Vpp (20 dBm)
CTRL ROOM Output
Spk - Stereo Line
Unbal.
Jack 1/4”
-inf to +6 dBm
Phones - Stereo Line
Unbal.
Jack 1/4”
0 to 24 Vpp (20 dBm)
