Each STEREO module has dual switchable stereo line inputs with optional three-band
EQ. Input A comes factory preset for Line, while input B may be set for Line signals
as well for RIAA PHONE signals via internal jumpers, so that a record-player can be
connected directly to the input. Normally input A is selected but by pressing B SEL
button the alternative input is selected.
The signal is routed via a Balance control and two stereo routing switches to either the
main stereo programme (Master) or the stereo subgroup (Sub).
The PFL switch makes the pre-fade signal available for monitoring.
ALPS N-type 90° ultra smooth 100 mm sliders are provided on series. On request, to
notify at order, ALPS K/VCA series sliders can be also fitted, the last ones controlling
an internal high quality VCA circuitry.
Three Start/Stop interfaces are available as an option.
momentary, optoinsulated Start/Stop control from slider
(duplicated for Input A and B)
