AXEL | OXYGEN 4 SERIES - INTRODUCTION
1.3 OXYGEN 4 – AVAILABLE SCRIPT AND SLIDER (FADER)
No compromises have been made in either quality or features, particularly in the areas of switching, signaling, fader
start/stop and communication. Electronic components have been selected from the best on the market. Faders,
potentiometers and switches are by ALPS. Most all of the switches have led indicators and all similar functions are
grouped and colour coded, with additional fader knobs with different channel colour coding. Long throw, 100mm faders
give a smooth, repeatable response. VCA control for input module sliders is available as an option.
Slider stereo Alps K series with knob
Slider stereo Alps N 90° series with knob
Script Tray module 8 units - 304 mm
(only for VMH frame)
Script Tray 10 units - 380 mm
(Only for 30ch frame)
1.4 OXYGEN 4 – MODULI A RICHIESTA (GIA’ PRESENTI NEL FRAME)
Power Supply Unit, rackmount 1u 19" with relay
unit module for On Air lamp control.
1.5 IMPORTANT NOTES
Start/Stop commands and VCA control options can not be fitted in the same Stereo module
1.6 THIS MANUAL
This User Manual has been developed for Oxygen 4 and Oxygen 4 VMH series.
