Chapter 9. LIST OF COMMUNICATION DATA
Bank Item name
RAM address EEPROM address RAM EEPROM
Decimal
point
information
Notes
Decimal Hexadecimal Decimal Hexadecimal Read Write Read Write
Tag Tag 4 9304 2458 25688 6458 — Display and setting cannot be
made with the console.
Tag 5
9305 2459 25689 6459 — Same as above.
Tag 6
9306 245A 25690 645A — Same as above.
Tag 7
9307 245B 25691 645B — Same as above.
Tag 8
9308 245C 25692 645C — Same as above.
Tag 9
9309 245D 25693 645D — Same as above.
Tag 10
9310 245E 25694 645E — Same as above.
Tag 11
9311 245F 25695 645F — Same as above.
Tag 12
9312 2460 25696 6460 — Same as above.
Tag 13
9313 2461 25697 6461 — Same as above.
Tag 14
9314 2462 25698 6462 — Same as above.
Tag 15
9315 2463 25699 6463 — Same as above.
Tag 16
9316 2464 25700 6464 — Same as above.
PID
Proportional band (
P-1
)
12288 3000 28672 7000 1
Integration time (
I-1
)
12289 3001 28673 7001 S
Derivative time (
D-1
)
12290 3002 28674 7002 S
Manual reset (
RE-1
)
12291 3003 28675 7003 1
MV low limit (
OL-1
)
12292 3004 28676 7004 1
MV high limit (
OH-1
)
12293 3005 28677 7005 1
Proportional band (
P-2
)
12294 3006 28678 7006 1
Integration time (
I-2
)
12295 3007 28679 7007 S
Derivative time (
D-2
)
12296 3008 28680 7008 S
Manual reset (
RE-2
)
12297 3009 28681 7009 1
MV low limit (
OL-2
)
12298 300A 28682 700A 1
MV high limit (
OH-2
)
12299 300B 28683 700B 1
Proportional band (
P-3
)
12300 300C 28684 700C 1
Integration time (
I-3
)
12301 300D 28685 700D S
Derivative time (
D-3
)
12302 300E 28686 700E S
Manual reset (
RE-3
)
12303 300F 28687 700F 1
MV low limit (
OL-3
)
12304 3010 28688 7010 1
MV high limit (
OH-3
)
12305 3011 28689 7011 1
Proportional band (
P-4
)
12306 3012 28690 7012 1
Integration time (
I-4
)
12307 3013 28691 7013 S
Derivative time (
D-4
)
12308 3014 28692 7014 S
Manual reset (
RE-4
)
12309 3015 28693 7015 1
MV low limit (
OL-4
)
12310 3016 28694 7016 1
MV high limit (
OH-4
)
12311 3017 28695 7017 1
Proportional band (
P-5
)
12312 3018 28696 7018 1
Integration time (
I-5
)
12313 3019 28697 7019 S
Derivative time (
D-5
)
12314 301A 28698 701A S
Manual reset (
RE-
5)
12315 301B 28699 701B 1
MV low limit (
OL-5
)
12316 301C 28700 701C 1
MV high limit (
OH-5
)
12317 301D 28701 701D 1
Proportional band (
P-6
)
12318 301E 28702 701E 1
Integration time (
I-6
)
12319 301F 28703 701F S
Derivative time (
D-6
)
12320 3020 28704 7020 S
Manual reset (
RE-6
)
12321 3021 28705 7021 1
MV low limit (
OL-6
)
12322 3022 28706 7022 1
MV high limit (
OH-
6)
12323 3023 28707 7023 1
Proportional band (
P-7
)
12324 3024 28708 7024 1
(Continue on next page.)
