Chapter 9. LIST OF COMMUNICATION DATA
Bank Item name
RAM address EEPROM address RAM EEPROM
Decimal
point
information
Notes
Decimal Hexadecimal Decimal Hexadecimal Read Write Read Write
PID (Reserved for future extension.) 12375 3057 28759 7057
∆ ∆ ∆ ∆
—
Cool-side MV low limit (
OL7.C
)
12376 3058 28760 7058 1
Cool-side MV high limit (
OH7.C
)
12377 3059 28761 7059 1
Cool-side proportional ban
(
P-8.C
)
12378 305A 28762 705A 1
Cool-side integration time (
I-8.C
)
12379 305B 28763 705B S
Cool-side derivative time (
D-8.C
)
12380 305C 28764 705C S
(Reserved for future extension.) 12381 305D 28765 705D
∆ ∆ ∆ ∆
—
Cool-side MV low limit (
OL8.C
)
12382 305E 28766 705E 1
Cool-side MV high limit (
OH8.C
)
12383 305F 28767 705F 1
Event Internal Event 1 main setting 13056 3300 29440 7300 S
Internal Event 1 sub-setting 13057 3301 29441 7301 S
Internal Event 2 main setting 13058 3302 29442 7302 S
Internal Event 2 sub-setting 13059 3303 29443 7303 S
Internal Event 3 main setting 13060 3304 29444 7304 S
Internal Event 3 sub-setting 13061 3305 29445 7305 S
Internal Event 4 main setting 13062 3306 29446 7306 S
Internal Event 4 sub-setting 13063 3307 29447 7307 S
Internal Event 5 main setting 13064 3308 29448 7308 S
Internal Event 5 sub-setting 13065 3309 29449 7309 S
Internal Event 6 main setting 13066 330A 29450 730A S
Internal Event 6 sub-setting 13067 330B 29451 730B S
Internal Event 7 main setting 13068 330C 29452 730C S
Internal Event 7 sub-setting 13069 330D 29453 730D S
Internal Event 8 main setting 13070 330E 29454 730E S
Internal Event 8 sub-setting 13071 330F 29455 730F S
LSP LSP1 13312 3400 29696 7400 P
LSP2 13313 3401 29697 7401 P
LSP3 13314 3402 29698 7402 P
LSP4 13315 3403 29699 7403 P
LSP5 13316 3404 29700 7404 P
LSP6 13317 3405 29701 7405 P
LSP7 13318 3406 29702 7406 P
LSP8 13319 3407 29703 7407 P
Instrument
status 1
Typical alarm 14336 3800 30720 7800 X X —
Bit 0: PV failure (
AL0 1
to
03
)
Bits 1 to 11: Undefined.
Bit 12: Hardware failure (
AL70
)
Bit 13: Parameter failure
(
AL95
/
97
)
Bit 14: Adjustment data failure
(
AL96
/
98
)
Bit 15: ROM failure (
AL99
)
DO status
14337 3801 30721 7801 X X — Same as RAM address 9205
(decimal).
DI status
14338 3802 30722 7802 X X — Same as RAM address 9206
(decimal).
(Continue on next page.)
