Page #252 background imageLoading...
Page #252 background image
9-16
Chapter 9. LIST OF COMMUNICATION DATA
Bank
Item name
RAM address EEPROM address RAM EEPROM
Decimal
point
information
Notes
Decimal
Hexadecimal
Decimal
Hexadecimal
Read Write Read Write
Instrument
status 2
RUN/READY
14352 3810 30736 7810 X X
AUTO/MANUAL
14353 3811 30737 7811 X X
AT stop/start
14354 3812 30738 7812 X X
LSP/RSP
14355 3813 30739 7813 X X Writing is enabled under no
DI Assignment conditions.
Same as RAM address
9003(decimal).
PV
14356 3814 30740 7814 X X P
SP (Target value)
14357 3815 30741 7815 X X P
Manipulated Variable (MV)
14358 3816 30742 7816 X X 1
Instrument
status 3
RSP
14416 3850 30800 7850 X X P
Same as RAM address 7001
(decimal).
MFB (Motor opening feedback
value)
14417 3851 30801 7851 X X 1
Same as RAM address 9108
(decimal).
Current transformer (CT) input 1
current value
14418 3852 30802 7852 X X 1
Same as RAM address 9110
(decimal).
Current transformer (CT) input 2
current value
14419 3853 30803 7853 X X 1
Same as RAM address 9111
(decimal).
Heat MV (for heat/cool control)
14420 3854 30804 7854 X X 1
Same as RAM address 9106
(decimal).
Cool MV (for heat/cool control)
14421 3855 30805 7855 X X 1
Same as RAM address 9107
(decimal).
Operation
LSP group selection
14592 3900 30976 7900 * *
Writing is enabled under no DI
Assignment conditions.
Same as RAM address 9103
(decimal).
LSP value in use
14593 3901 30977 7901 P
Same as RAM address 9123
(decimal).
Manual manipulated variable (MV)
14594 3902 30978 7902 * * 1
Writing is enabled in the
MANUAL mode.
Same as RAM address 9105
(decimal).
RUN/READY
14595 3903 30979 7903 * *
Writing is enabled under no DI
Assignment conditions.
Same as RAM address 9002
(decimal).
AUTO/MANUAL
14596 3904 30980 7904 * *
Writing is enabled under no
DI Assignment and other
conditions.
Same as RAM address 9001
(decimal).
AT stop/start
14597 3905 30981 7905 * *
Writing is enabled under no
DI Assignment and other
conditions.
Same as RAM address 9004
(decimal).
LSP/RSP
14598 3906 30982 7906 * *
Writing is enabled under no DI
Assignment conditions.
Same as RAM address 9003
(decimal).
(Continue on next page.)
