Azbil MagneW FLEX+ - 2: Remote Type; Figure 1-3 Remote Configuration

Azbil Corporation Introduction
MagneW FLEX+/PLUS+ Electromagnetic Flowmeter Detector 1-3
1.2.2: Remote type
AC power supply
Pulse output,
Contact input/output
Analog output/
Digital output
Excitation output
Flow signal input
Converter
Dedicated cable
Detector
Direction of fluid
Figure 1-3 Remote Conguration
