Installation Azbil Corporation
2-26 MagneW FLEX+/PLUS+ Electromagnetic Flowmeter Detector
2.5.1: Determining the fastening torque
The following table shows the fastening torque for each pipe bore.
CAUTION
The correct fastening torque must be used to prevent leakage. To avoid damage to
the detector, do not exceed the listed fastening torque.
Table 2-6 Fastening torque for anged detectors
Nominal
detector bore
diameter
mm (inch)
Flange ratings
Fastening torque
N•m (ft•lb)
kgf•cm
2.5 - 15 mm
(0.1 - 3/8 inch)
JIS 10K
JIS 20K
JIS 30K
6 - 9
6 - 9
18 - 31
(4.4 - 6.6)
(4.4 - 6.6)
(13.3 - 22.9)
61 - 92
61 - 92
184 - 316
JPI 150
JPI 300
ANSI 150
ANSI 300
6 - 9
6 - 9
(4.4 - 6.6)
(4.4 - 6.6)
61 - 92
61 - 92
DIN PN10/16
DIN PN25/40
6 - 9
9 - 14
(4.4 - 6.6)
(6.6 - 10.3)
61 - 92
92 - 143
25 mm
(1 inch)
JIS 10K
JIS 20K
JIS 30K
21 - 31
21 - 32
23 - 36
(15.5 - 22.9)
(15.5 - 23.6)
(17.0 - 26.6)
214 - 316
214 - 326
235 - 367
JPI 150
JPI 300
ANSI 150
ANSI 300
11 - 17
22 - 34
(8.1 - 12.5)
(16.2 - 25.1)
112 - 173
224 - 347
DIN PN10/16
DIN PN25/40
10 - 14
12 - 18
(7.4 - 10.3)
(8.9 - 13.3)
102 - 143
122 - 184
40 mm
(1½ inches)
JIS 10K
JIS 20K
JIS 30K
22 - 32
22 - 34
41 - 65
(16.2 - 23.6)
(16.2 - 25.1)
(30.2 - 47.9)
224 - 326
224 - 347
418 - 663
JPI 150
JPI 300
ANSI 150
ANSI 300
13 - 18
36 - 57
(9.6 - 13.3)
(26.6 - 42.0)
133 - 184
367 - 581
DIN PN10/16
DIN PN25/40
22 - 32
25 - 38
(16.2 - 23.6)
(18.4 -28.0)
224 - 326
255 -387
