17
Description of the device
No. Element Meaning
5
Back key:
Return to the last display or last menu level
6
Lock/unlock symbol:
The keypad is locked and unlocked by pressing and holding
down the menu key.
7
Menu key:
Call up main menu and lock/unlock the device
8
Info key:
Call up therapy data from the current infusion
9
Bolus key:
Initiate bolus administration
10
Start/Stop key:
Start/stop the infusion
38932401_Infusomat_compactPlusP_EN_IFU_1020_v5.indd 17 15.10.2020 17:47:26
