Baldor MicroFlex Installation Manual

www.baldormotion.com
A-10 Accessories MN1919
A.2.2 Feedback cable part numbers
A description of a feedback cable catalog number is shown here, using the example number
CBL025SF-E2:
Meaning Alternatives
CBL The item is a cable -
025 Indicates the length, in this example 2.5 meters Various lengths are available.
SF ThecableisaServo motor Feedback cable -
E Encoder feedback cable with motor connector
S=SSI feedback cable
R=Resolver feedback cable
2
Drive connector included:
15-pin D-type connector for all feedback types
1=Drive connector included:
9-pin D-type connector (for
Resolver)
Note: Feedback cables have the outer shield tied to the connector housing(s).
If you are not using a Baldor cable with your chosen feedback device, be sure to obtain a cable
that is a shielded twisted pair 0.34 mm
2
(22 A WG) wire minimum, with an overall shield. Ideally ,
the cable should not exceed 30.5 m (100 ft) in length. Maximum wire-to-wire or wire-to-shield
capacitance is 50 pF per 300 mm (1 ft) length, to a maximum of 5000 pF for 30.5 m (100 ft).
A.2.3 SSI feedback cables
A.2.3.1 Cables available in North and South America
C
a
b
l
e
a
s
s
e
m
b
l
y
d
e
s
c
r
i
p
t
i
o
n
C
a
t
a
l
o
g
n
u
m
b
e
r
Length
C
a
b
l
e assem
b
l
y
d
esc
r
i
p
t
i
on
C
a
t
a
l
og num
b
e
r
m ft
SSI feedback cable:
no connectors
CBL044-501 Available by the foot or
on 100 m (328 ft) drum.
Feedback cable assembly:
CE style threaded motor connector
and low density 15-pin D-type drive
connector
CBL015SF-S2
CBL030SF-S2
CBL061SF-S2
CBL091SF-S2
CBL152SF-S2
CBL229SF-S2
1.5
3.0
6.1
9.1
15.2
22.9
5
10
20
30
50
75
A.2.3.2 Cables available in the rest of the world
C
a
b
l
e
a
s
s
e
m
b
l
y
d
e
s
c
r
i
p
t
i
o
n
C
a
t
a
l
o
g
n
u
m
b
e
r
Length
C
a
b
l
e assem
b
l
y
d
esc
r
i
p
t
i
on
C
a
t
a
l
og num
b
e
r
m ft
SSI feedback cable:
no connectors
CBL044-501 Available by the meter
or on 100 m drum.
Feedback cable assembly:
CE style threaded motor connector
and low density 15-pin D-type drive
connector
CBL025SF-S2
CBL050SF-S2
CBL075SF-S2
CBL100SF-S2
CBL150SF-S2
CBL200SF-S2
2.5
5.0
7.5
10
15
20
8.2
16.4
24.6
32.8
49.2
65.6
