2-2 Introduction MN1919
2.2 Receiving an d insp ectio n
When you receive your MicroFlex, there are several things you should do immediately:
1. Check the condition of the shipping container and report any damage immediately to the
carrier that delivered your MicroFlex.
2. Remove the MicroFlex from the shipping container and remove all packing material. The
container and packing materials may be retained for future shipment.
3. Verify that the catalog number of the MicroFlex you received is the same as the catalog
number listed on your purchase order . The catalog number is described in the next section.
4. Inspect the MicroFlex for external damage during shipment and report any damage to the
carrier that delivered your MicroFlex.
5. If MicroFlex is to be stored for several weeks before use, be sure that it is stored in a location
that conforms to the storage humidity and temperature specifications shown in section 8.1.14.
2.2.1 Identifying the catalog number
The MicroFlex is available with different current ratings. The catalog number is marked on the
side of the unit. It is a good idea to look for the catalog number (sometimes shown as ID/No: )
and write it in the space provided here:
Cata log number:
FMH______________-________
Installed at: ________________________
Date: ______
A description of a catalog number is shown here, using the example FMH2A03TR-EN23:
Meaning Alternatives
FMH MicroFlex family -
2 Requires an AC supply voltage of 115-230 Volts, 1Φ or 3Φ -
A03 Continuous current rating of 3A
A01=1A; A06=6A;
A09=9A
T Built in AC power supply -
R Requires external braking resistor -
E Supported feedback types are encoder or SSI R=Resolver feedback
N No options specified -
2 Serial port type is RS232 4 = RS485
3 24VDC supply is required to power the control logic -
