5-8 Input / Output MN1919
NextMove ESB / controller
MintMT
OUTX.0
10k
DOUT0
USR GND
1
10
UDN2982
User
supply
24V
User
supply
GND
USR V+
9
‘X11’
DIN0+
MicroFlex
DIN0-
‘X3’
100R
TLP280
3k3
5
4
Figure 31 - Digital input - typical connection from a Baldor NextMove ESB
