www.baldormotion.com
Input / Output 5-13MN1919
NextMove ESB / controller
Status+
Status-
8
9
MicroFlex
DIN4
CREF1
NEC PS 2562L-1
3k3
TLP280
User
supply
GND
User
supply
24V
3
2
‘X3’
‘X9’
Figure 37 - Status output - typical connections to a Baldor NextMove ESB
