BALTECH VP-3470
Operation manual
Programs and functions 39
Table 4. Programs and functions
PROGRAM FUNCTION BRIEF DESCRIPTION
MEASUREMENTS
Overall
Performs vibration measurement (vibration
velocity, vibration displacement, vibration
acceleration) in a defined frequency range.
Routes
Performs the route measurements set in the
database management software BALTECH
EXPERT.
Time
waveform
Allows the user to view the vibration
waveform.
Spectrum
Allows the user to view the vibration
spectrum.
Envelope Allows the user to view the envelope.
Envelope
spectr
Allows the user to view the spectral
components of the envelope.
Peak and
phase
Detects the amplitude and phase of the
vibration signal relative to the tachometer or
stroboscope.
Turning
speed
Measures the rotor speed using the
tachometer or stroboscope.
BALANCING
New
balancing
Performs balancing of rotating parts.
Manual input
Calculates the balancing weights and
installation angle based on the existing data
on the vibration amplitude and phase.
Re-balancing Performs balancing using the saved data.
ICM
Performs balancing using existing dynamic
influence coefficients.
Vector math
Calculates the place of installation of the
balancing weights if the recommended
installation places are not available.
REPORTS
Open
Allows the user to open and view the saved
reports.
Delete Allows the user to delete the saved reports.
Send to PC
Allows the user to transfer the saved reports
into PC.
Control from
PC
Allows connecting the device to PC to perform
control from the PC.
