5. Installing ClickShare
5. INSTALLING CLICKSHARE
WARNING: D o not connect to the mains power during installation.
WARNING: Only use the an tennas that are delivered with the p rod uct. Other an tennas are not allowed.
Overview
• Installation methods for the Base unit
• Table mounting
• Wall mounting
• Ceiling mounting
• Rack mounting
5.1 Installation m ethods for the Base unit
For optimal performance, install the Base Unit close to the display and avo id ob stacles between the Base Unit
and the Buttons. Do not block the fan inlets and o utlets of the Base Unit!
Introduction to the installation methods
The base unit can be installed in different ways in a meeting room:
• Table mounted
• Wall mounted
• Ceiling mounted
• Rack mounted
The antennas are removable. They can be fixed to the Base Unit depending on the way the Base Unit is installed in the room. The
antennas can rotate for better wireless connection.
Using extension cables for the antennas is allowed, b ut this can reduce the performance.
5.2 Table mounting
Overview
Put the Base Unit directly on the meeting room table.
The total weight of the Base Unit is 2,6 kg.
CAUTION: Wh en p lacing the Bas e U nit inside a closed cabinet, make sure there is sufficient ventilation for
hot air exhaust.
R5900006 CLICKSHARE 04/12/2013 23
