Barco ClickShare Service Guide

6. Connecting
6.7 Advanced Use
Advanced functionality
ClickShare can show the content of up to four wireless sources or three wireless sources and one ClickShare Link (for an iPad) on
the meeting room display(s) at the same time. A wireless source is a ClickShare Button, or either an iPad or android device sharing
via the ClickShare app. This means by clicking their Button, clicking the virtual button in the ClickShare app or connecting an iOS
device through the ClickShare Link, four persons in the meeting room can display their screens simultaneously. They appear as
follows:
For a meeting room with a single display:
1 user
1
2 users
12
3 users
12
3
4 users
4
12
3
Image 6-29
Position on single display
For a meeting room with a dual display:
1 user
2 users
3 users
4 users
1
1
3
1 2
12
12 34
Image 6-30
Position on Dual screen
One display must support Display Port, otherwise an adapter piece from display port to DVI must be used.
For a single display 2560x1080 Panoramic setup
40 R5900006 CLICKSHARE 04/12/2013

Barco ClickShare Specifications

General

Plug-and-Play	Yes
Video Outputs	HDMI
Supported Resolutions	Up to 4K UHD
Number of Concurrent Users	Up to 8 (depending on the specific model)
Operating System Compatibility	Windows, macOS
Security Protocols	WPA2
Maximum Resolution	3840x2160
Connection	USB
Encryption	AES
Supported Video Formats	H.264
Wireless Technology	Wi-Fi
