5. Installing ClickShare
5.3 Wall m ounting
About wall mounting
Use the mounting brackets, inserted in the ClickShare box, to mount the Base unit on the wall.
The total weight of the Base Unit — including the mounting brackets — is 2,9 kg.
Necessary tools
• a drill (type of drill depends on the type of wall)
• Torx T10 screwdriver
• Additional screwdriver that matches the mounting screws (mounting screws not delivered)
Necessary parts
• 2 mounting screws
• 2 plugs
• Mounting brackets (included in the ClickShare box)
How to install
1. Drill two holes in the wall, at a distance of 173 mm (6.81 inch) from each other on a horizontal line.
2. Insert a plug in each hole (if needed, depends on the wall type) and drive in the 2 screws. Make sure not to drive in the screws
fully so that the bracket can be hooked on the screws.
Note: Mounting screws and plug s are not included in the ClickShare box . The type of screws and plugs depend on the type
of wall (stone, wood, plasterboard, ...) you are mounting the Base Unit to. M ake s ure th e head of the screw is not larger
than the hole in the bracket.
3. Install the brackets on the Base Unit as shown on image 5-1. Use the mechanical fixation
points at the bottom of the Base Unit.
Note: Use the p re-mounted Pan Head T10 M 3 screws (refer to image 5-4) to m ount the brackets. Remove them from the Base
Unit and reuse them to fixatethebracketstotheBaseUnit.
24
R5900006 CLICKSHARE 04/12/2013
