Barco Loki User Manual

1. Safety
PR
RESTRICTED
AREA
RESTRICTED
AREA
Image 1-2
1.5 Hazard Distance for fully closed projection system
HD
Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface
unit becomes lower than the ap plicable expos ure limit on the cornea or on the skin. The light beam is considered (to
be) unsafe for exposure if the distance from a person to t
he light source is less than the HD.
Restriction Zone RZ Based on the HD
The projector is also suitable for rear proje
ction applications; projecting a beam onto a defuse co ated projection screen. As displayed
in image 1-3 two areas sho uld be considered: the restricted enclosed projection area ( RA) and the observation are a ( TH).
RA TH
sw
PD
HDDIFFUSE
sw
RZ
sw
sw
PR
HD
REFLECTION
RESTRICTED
AREA
RESTRICTED
AREA
Image 1-3
RA Restricted Access location (Enclosed projection area)
PR Projector.
TH Theater (observation area).
RZ Restriction Zone
PD Projection Distan
SW Separation Widt
h. Must be minimum 1 m eter.
Restriction zo
ne (RZ) based on the HD continued.
For this type of setup 3 different HD shall be considered:
601–426 F70 SERIES 24/10/2017
9
