6. Source menu
Image 6-5
Example of connector settings for an HD MI connector
5. You can change the following:
- To force a limit on the color space, select one of the available color spaces.
- To force a limit on the used signal range, select one of the available signal ran ges.
- To set a video timing o ther than the one native f or the connector, select one of the options under EDID.
Note: You cannot c hange the EDID for SDI conne ctors.
6.3 Using Dual inputs
Dual Input.
For extended flexibility to connect high resolution sources with a pixel clock over 330 MH z, the projector is supporting a du a l input
mode. In this mode, the left and the right half of the image can be connected to the DV I-1 and DVI-2 respectively, or DP1 and DP2.
To enable this mode, select the source that fits in the menu Home/Sou rce
Dual input modes
There are four ways to connect dual input.
• Dual Displayport Columns
• Dual Displayport Sequential
• Dual D VI Columns
• Dual D VI Sequential
For Images to be displayed in this mode, the resolution must be the same on both chan nels
Signal source setup.
When using d ual inputs, it is important that the signal sources are set up correctly, with the co rrect resolution. P lease refer to the
manual for the source itself (PC, G raphic driver card..) in or der to obtain a correct setup. If the setup is wrong, no picture will be
visible in dual m ode.
The resolution for each dual column channel can be up to 1920x2400 pixels.
The resolution for each dual sequential channel can be up t o 3840x2400 pixels. ( 4K)
Change the E DID f or each channel to the correct value. See "Connector Settings", pag e 49 for EDID setup .
601–426 F70 SERIES 24/10/2017 51
