5. Getting started

5. GETTING STARTED

About this chapter

This chapter describes how to set up and optimize your projector setup w hen the physical installation p rocess is complete.

Overview

• Projector source and control connections

• Power up the projector

• Power down the projector

• Power m ode transitions

• Power m odes

• Customize projector s ettings

• User interface

5.1 Projector source and control connections

Overview

• Making c onnections

• Connector spec iﬁcat ion s

• Control interfaces

5.1.1 Making connections

The source switching time varies from 0.5 to 5 seconds.

Source signal connectivity

The connector panel at the back of the projector is used for all source connections.

Source signal connectivity on the projector is:

• 2x Dual Link DVI-I (DVI-D functionality)

• 2x DisplayPort 1.2

• 1x HDM I 2.0

• 1x HDB aseT

•1x3GSDI

5.1.2 Connector speciﬁcations

Overview

•DVI-I

• Display Port 1.2

• HDMI 2.0

•3G-SDI

• HDBase T

5.1.2.1 DVI-I

Speciﬁ ca tions

Param eter Value

Connector DVI-I fem ale digital RGB

Signal characteristics DVI 1.0, Digital, TMDS

601–426 F70 SERIES 24/10/2017 41

Barco Loki User Manual

Other manuals for Barco Loki
