8. Installation menu
8. INSTALLATION MENU
Overview
• IR / Night vision functionality
• Lens
• Orientation
• Warping
• Blending
• Illumination
• Display Setup
8.1 IR / Night vision functionality
About
IR / Night Vision functionality is only available for the FS variant of the projector..
In combination with Night Vision Goggles (NVG), this will give a realistic rendering of the environment. This w ill visualize in a realistic
way, night time, dusk and dawn, and limited visibility sc enarios.
The IR light source has a wavelength of 740nm
How to enable IR/Night Vision.
Enter the menu Home / Installation / Display setup an d select NightVision in the scroll down menu.
Image 8-1
To set up the IR illumination, enter the menu Home/Installation/Illumination/Power. T his menu shows two sliders; one for the Laser,
and one for the IR LE D. The sliders are scaled from zero – 100% power.
601–426 F70 SERIES 24/10/2017
63
