Barco Loki User Manual

3. Lenses
Name Description Part number Weight
FLD+ Lens 1.7 - 2.5 : 1 (EN41) 1.58 - 2 .33 : 1 (WUXGA) / 1.7 - 2.5 : 1
(WQXGA)
R9801216 2.54 kg
FLD+ NV Lens 1.7 - 2.5 : 1
(NV41)
IR Optimized, 1.58 - 2.33 : 1 (WU XGA ) /
1.7-2.5:1(WQXGA)
R9801216 2.54 kg
FLD+ Len s 0.8 : 1 (EN42) 0.75 : 1 (WUXGA) / 0.8 : 1 (WQ XG A)
R9801226 2.7 kg
FLD+ Lens 1.2 - 1.7 : 1 (EN43) 1.12 - 1 .58 : 1 (WUXGA) / 1.2 - 1.7 : 1
(WQXGA)
R9801230 2.84 kg
FLD+ NV Lens 1.2 - 1.7 : 1
(NV43)
IR Optimized, 1.12 - 1.58 : 1 (WU XGA ) /
1.2-1.7:1(WQXGA)
R9801286 2.84 kg
FLD+ Lens 2.5 - 4.6 : 1 (EN44) 2.33 - 4.3 : 1 (WUX GA) / 2.5 - 4.6 : 1
(WQXGA)
R9801211 3.08 kg
FLD+ Lens 0 .75 - 1 .13 : 1 (EN45) 0.75 - 1.13 : 1 (WUXG A) / 0.8 - 1.21 :
1(WQXGA)
R9801220 3.04 kg
FLD+ Lens 0 .75 - 1 .13 : 1 (EN46) 0.75 - 1.13 : 1 (WUXG A) / 0.8 - 1.21 :
1(WQXGA)
R9801221 3.14 kg
FLD+ NV Lens 0.8 - 1.21 : 1
(NV46)
IR Optimized, 0.75 - 1.13 : 1 (WUXG A)
/ 0.8 - 1.21 : 1 (W QXG A)
R9801287 3.14 kg
FLD+ Lens 0.65 : 1 (EN47) 0.61 : 1 (WU XGA) / 0.65 : 1 (WQXG A) R9801295 5.4 kg
Name Working F# Iris / Iris F# Zoom Ratio Focal Length
(mm)
Focus Ran ge ( m)
FLD+ Lens 1.7 -
2.5 : 1 (EN41)
2.1-2.5 Yes 2.1-6.5 1.47 33.70-49.54 1.5 - 15
FLD+ NV Lens 1.7
- 2.5 : 1 (NV41)
2.1-2.5 Yes 2.1-6.5 1.47 33.70-49.54 1.5 - 15
FLD+ L ens 0.8 : 1
(EN42)
2.1 Yes 2.1-6.5
-
16.12 0.7 - 7
FLD+ Lens 1.2 -
1.7 : 1 (EN43)
2.4-2.7 Yes 2.4-6.5 1.42 23.95-34.02 1.5 - 15
FLD+ NV Lens 1.2
- 1.7 : 1 (NV43)
2.4-2.7 Yes 2.4-6.5 1.42 23.95-34.02 1.5 - 15
FLD+ Lens 2.5 -
4.6 : 1 (EN44)
2.1-2.93 Yes 2.1-6.5 1.85 49.52-91.60 2.5-25
FLD+ Lens 0.75 -
1.13 : 1 (EN45)
2.4-3.29 Yes 2.4-6.5 1.51 15.85-23.93 5.0 - 30
FLD+ Lens 0.75 -
1.13 : 1 (EN46)
2.4-3.29 Yes 2.4-6.5 1.51 15.98-23.99 0.7 - 7
FLD+ NV Lens 0.8
-1.21: 1(NV46)
2.4-3.29 Yes 2.4-6.5 1.51 15.98-23.99 0.7 - 7
FLD+ Lens 0.65 :
1 (EN47)
2.1 Yes 2.1-6.0
-
12.6 0.5 - 4.0
3.3 Replace a lens
Lens l ever
The F70 lens m ount and lens lever is des igned to prevent dam age to the lens board while providing an easy and stable lens change
procedure.
The lens lever, located at the bottom of the lens mount, slides between two positions, far left (default position — unlocked) and far
right (locked).
Always activate the projector shutter b efore attempting to remove or install a lens.
To do t his, p ress t he shutter button on the keyp ad, or shutter Close on the remote, to activate the shutter. The
keypad button will illuminate red when the shutter is activated.
Press the shutter button again, or shutter Open o n the remo te, to deactivate the shutter and resu me normal
operation. T he keypad button will illuminate white w hen the shutter is deactivated.
601–426 F70 SERIES 24/10/2017 27
