8. Installation menu
Picture frame
Projector 1
Picture frame
Projector 2
Width, Projector 2Width, Projector 1
Overlap / Blend Zone
Image 8-35
The Mask adjustments.
The offset adjustments are used to cu t the image on each side. Normally used to hide part
s of the picture that shall not be shown
on the screen. An example can be: If the source is a pc, you may want to hide the m enu bar at the bottom of the screen.
8.5.2 Set up the system
How to set up the system
In this ch apter, the setup procedure for the projectors is exp lained, but a setup procedure m ust also be performed for the picture
source.
In order to obtain a satisfying result for the Blend f unction, the overlap / Blend zone are recomm en ded to be
at least 10% of the picture width.
The basic principle is that the ove rlap setup in the source sh
all correspond with the blend w idth setup for the projector. That means
that if the over lap zone for the source is set to 500 pixels, the width of the blend zone for the projector also mus t be set to 500 pixels.
First step is to align the image from the projectors as accurate as possible in a mechanical way, meaning without any optical correc-
tions. At t he same time, establish a n overlap in the pictures between the two screens.
Then adjust the remaining irregularities by using the shift and warp features in the pr ojectors to obtain the las t fine tuning of the
alignment.
Setup the source to a blend which corresponds with the pr eset overlap on the screen. There are different way s to do this, d epending
on the source. Refe r to the source unit’s m anual for this issue.
Adjust the Blend for the projectors as descri
bed below.
8.5.3 Adjustment Procedure
Blend adjustment procedure
Entering the Blend Adjustme nt from the Home menu, either by the remote control, or the keypad on the projector.Home/Installa-
tion/Blend And M ask/Blend Mask The menu shown below appea rs on the OSD.
The “Enable” button enables/disables the blend function. The “Show Lines” enables alignment lines on the screen, in order to
visualize the over lap/blend zon e.
76
601–426 F70 SERIES 24/10/2017
